The bootloader does not affect RAM usage.ĪTmega328P onboard chip in QFN package running at 3.3V logic

#Adafruit trinket uk pro

The bootloader on the Pro Trinket use 4KB of FLASH so the maximum sketch size is 28,672 bytes.

#Adafruit trinket uk code

The USB connection is for uploading new code only.

#Adafruit trinket uk serial

This is to keep the Pro Trinket small and inexpensive, you can use any FTDI cable to connect to the FTDI port for a Serial connection. You cannot plug shields directly into the Pro Trinket The onboard power supply is a 3.3V regulator and it can provide 150mA output Only the most timing-specific libraries may be affected, check the documentation! The NeoPixel Library works fine at 12MHz. The Pro Trinket 3V runs at 12MHz, this doesn't affect most projects. Pins #2 and #7 are not available (they are exclusively for USB) Here's some things you may have to consider when adapting Arduino sketches: Pro Trinket is programmable using the Arduino IDE as you already set up, and 95% of Arduino projects will work out of the box! However, it uses 3V logic and 12MHz clock which means it's good when you want a lower-power and lower-voltage setup. The Pro Trinket 3V uses the Atmega328P chip, which is the same core chip in the Arduino UNO/Duemilanove/Mini/etc. So it's great once you've finished up a prototype on an official Arduino UNO and want to make the project smaller. The Pro Trinket PCB measures only 1.5" x 0.7" x 0.2" (without headers) but packs the same capability as an Arduino UNO. We also added Optiboot support, so you can either program your Pro Trinket over USB or with a FTDI cable just like the Pro Mini and friends. Like the Trinket, it has onboard USB bootloading support - we opted for a MicroUSB jack this time. That's why we designed Pro Trinket, with 18 GPIO, 2 extra analog inputs, 28K of flash, and 2K of RAM. Trinket's a year old now, and while its been great to see tons of tiny projects, sometimes you just need more pins, more FLASH, and more RAM. It's like an Arduino Pro Mini with more pins and USB tossed in. To get such a tiny form-factor a few compromises had to be made, it doesn't have an Arduino serial port connection for debugging and some computer's USB V3 ports don't recognize the Trinket's bootloader, but USB V2 ports will.Trinket's got a big sister in town - the Pro Trinket 3V! Pro Trinket combines everything you love about Trinket with the familiarity of the core Arduino chip, the ATmega328. Power supply up to 16V DC, reverse polarity, thermal and current-limit protection.

8k bytes flash memory, 5 x GPIO lines including analogue inputs and PWM outputs.

male header pins for you to solder on as required.

#Adafruit trinket uk plus

Supplied as a fully assembled board plus 2 x 5-pin strips of 0.1in.

#Adafruit trinket uk free

Adafruit provide a free tutorial and example code to get you started, imagine driving 150 NeoPixels with such a dinky board. The board is capable of outputting 150mA and has an ultra-low drop-out regulator which will switch between USB and battery supply automatically. Its ATtiny85 processor has 8k bytes of flash (programme) memory, 512 bytes of SRAM (static RAM) and 512 bytes EEPROM and runs at 8MHz.

The Adafruit Trinket 3.3V mini-microcontroller is a tiny (27 x 15mm) Arduino compatible processor board which is programmable via its micro-USB socket.
